  • Code
    2089310-06
  • Height
    5.3 cm
  • Width
    27 cm
  • Operating Modes
    Semi-automated, manual, controlled by operator
  • Power Requirements
    1.0 A, 100-240 VAC, 50/60 Hz
  • Label Locations
    Alphanμmeric Location Names
  • Counting Efficiency
    50% at 0.3 µm (100% for particles > 0.45 µm)
  • Pump Repeatability
    ±5% Flow Rate
  • Battery Recharge Time
    3.5 hours
  • Battery
    Lithium Ion (rechargeable) battery
  • Throughput
    2.83 L per minute
  • Coincidence Loss
    10% at 4,000,000 particles/ft³
  • Industry Standards
    21 CFR Part 11 ISO 14644-1:2015 CE FCC
  • Color
    Gray
  • Depth
    10 cm
  • Environmental Conditions
    Indoor Environment
  • Count Alarms, Display & Cycles
    User-defined alarm counts, Raw counts: N/CF, N/CM, N/L in cumulative or differential mode
  • Zero Count
    Conforms to JIS B9921 (1 count or less in 5 min, 95% UCL)
  • Pump Accuracy
    ±5% Flow Rate
  • Battery Operating Time
    10+ hours (typical use) / minimum 5.5 hours (continuous sampling)
  • Data Storage
    10,000 records
  • Sample Volume
    10 µm
  • Particle Size Analysis Range
    0.3 to 10 μm
  • Platform
    APC Instruments
